Model HIT 1.2-K-UC Isolation Transformer
Product Details
As a general purpose dual-voltage isolation transformer for step-up (120 to 240 VAC), step-down (240 to 120 VAC), or straight 1:1 isolation (120 to 120 VAC or 240 to 240 VAC). Models with a suffix “UC” are provided with a safety jack for access to the transformer secondary center tap (connected to the transformer center tap only in the 240 VAC output setting). This connection may be used in conjunction with a Dielectric Voltage Withstand test.
Model HIT-5.0K-U Isolation Transformer
Product Details
As a general purpose dual-voltage isolation transformer for step-up (120 to 240 VAC), step-down (240 to 120 VAC), or straight 1:1 isolation (120 to 120 VAC or 240 to 240 VAC). Models with a suffix “UC” are provided with a safety jack for access to the transformer secondary center tap (connected to the transformer center tap only in the 240 VAC output setting). This connection may be used in conjunction with a Dielectric Voltage Withstand test.
Model HIT-7.5K-U Isolation Transformer
Product Details
This transformer is a general purpose dual-voltage "international" isolation transformer = for step-up (120 to 240 VAC), step-down (240 to 120 VAC), or straight 1:1 isolation (120 to 120 VAC or 240 to 240 VAC). This isolation transformer is constructed with double insulation which includes an insulated ground shield between the primary and secondary windings. The secondary winding is not grounded (no neutral). NOTE: In many countries "ground" is referred to as "earth." You may interchange the word "earth" with "ground." NOTE: The input voltage rating has a ± 10% Tolerance = it may be used for 110/220 VAC, 115/230 VAC, or 120/240 VAC application.
This transformer is a general purpose dual-voltage "international" isolation transformer = for step-up (120 to 240 VAC), step-down (240 to 120 VAC), or straight 1:1 isolation (120 to 120 VAC or 240 to 240 VAC). This isolation transformer is constructed with double insulation which includes an insulated ground shield between the primary and secondary windings. The secondary winding is not grounded (no neutral). NOTE: In many countries "ground" is referred to as "earth." You may interchange the word "earth" with "ground." NOTE: The input voltage rating has a ± 10% Tolerance = it may be used for 110/220 VAC, 115/230 VAC, or 120/240 VAC application.
Model HIT-10.0K-UC Isolation Transformer
Product Details
This transformer is a general purpose dual-voltage "international" isolation transformer = for step-up (120 to 240 VAC), step-down (240 to 120 VAC), or straight 1:1 isolation (120 to 120 VAC or 240 to 240 VAC). This isolation transformer is constructed with double insulation which includes an insulated ground shield between the primary and secondary windings. The secondary winding is not grounded (no neutral). NOTE: In many countries "ground" is referred to as "earth." You may interchange the word "earth" with "ground." NOTE: The input voltage rating has a ± 10% Tolerance = it may be used for 110/220 VAC, 115/230 VAC, or 120/240 VAC application
This transformer is a general purpose dual-voltage "international" isolation transformer = for step-up (120 to 240 VAC), step-down (240 to 120 VAC), or straight 1:1 isolation (120 to 120 VAC or 240 to 240 VAC). This isolation transformer is constructed with double insulation which includes an insulated ground shield between the primary and secondary windings. The secondary winding is not grounded (no neutral). NOTE: In many countries "ground" is referred to as "earth." You may interchange the word "earth" with "ground." NOTE: The input voltage rating has a ± 10% Tolerance = it may be used for 110/220 VAC, 115/230 VAC, or 120/240 VAC application
Series Variac Variable Transformers
Product Details
Also known as a varlac, this device allows you to adjust the input voltage to the product you are testing. If you don't need frequency adjustment, this is a much lower cost alternative to a power source. Output is fused. Single phase units noted below, 3 phase units available. Standard models include input voltages from 120VAC to 480VAC. Frequencies to 2000 Hz can be accommodated. Special units for voltages to 1000 VAC are available.
